TSC TE200 Series Desktop Barcode Printers (TE200 / TE210)

Model TSC TE-200 Series Brand TSC Printers

The TE200 Series provides customers worldwide with a competitive, durable, entry-level desktop printer that's both versatile and easy to use. Its modular thermal transfer print mechanism, protected by an outer ABS shell, is designed to withstand tough environments — printing high-quality labels all day long, producing thousands of clear, crisp barcode and identification labels per day.

The series' innovative design also offers integration opportunities: the print mechanism, which normally resides within the printer, can be purchased separately for building custom label printing capability into other manufactured designs — including kiosk applications, small label applicators, two-color on-demand printing, and two-sided printing.

Key Features

Modular thermal transfer print mechanism, protected by a rugged outer ABS shell
Energy Star 2.0 rated, energy-saving design
Easy-to-load print mechanism accepting 0.5" core (72–110m) or 1" core (300m) thermal transfer ribbons
Multiple printer language emulations out of the box, with a powerful scalable font engine — easy to replace nearly any existing label printer
Toolless printhead and platen roller replacement
Gap and Black Mark sensing for accurate label registration
Media cabinet handles industry-standard 5" OD labels on 1" or 1.5" cores
Powerful hybrid electric motor, strong enough for larger 8" OD label rolls via optional external label unwinder
Fast 400 MHz processor
Standard 1-year warranty
TE210 adds Ethernet, Wi-Fi, and an optional guillotine cutter/peel-off module for higher-capacity, more connected deployments

Applications

Work-in-progress and item labels, instruction labels, agency labels, patient identification, pharmacy and specimen identification, shipping and receiving labels, file folder labels, product identification, price tags, shelf labels, and jewelry tags. Well suited for automobile service shops, walk-in shipping and mail centers, and stockroom inventory control.

Request a quote Book a demo

Specification

	TE200	TE210
Print Resolution	203 dpi (8 dots/mm)	203 dpi (8 dots/mm)
Print Method	Direct thermal / thermal transfer	Direct thermal / thermal transfer
Display	LED with buttons	LED with buttons
Max. Print Speed	6 ips (152mm/s)	6 ips (152mm/s)
Max. Print Width	4.25" (108mm)	4.25" (108mm)
Max. Print Length	110" (2,794mm)	1,000" (25,400mm)*
RAM	16 MB SDRAM	64 MB SDRAM
Flash	8 MB	128 MB
Optional Cutter	N/A	Guillotine cutter (full cut and partial cut)
Internal Label Capacity	5" (127mm) OD	5" (127mm) OD
Max. Media Width	0.8"–4.4" (20–112mm)	0.8"–4.4" (20–112mm)
Media Types	Continuous, die-cut, black mark, fan-fold, notched (outside wound)	Continuous, die-cut, black mark, fan-fold, notched (outside wound)
Max. Ribbon Length	300 meters	300 meters
Max. Ribbon Width	1.6"–4.3" (40–110mm)	1.6"–4.3" (40–110mm)
Media Core Diameter	1"–1.5" (25.4–38mm)	1"–1.5" (25.4–38mm)
Hardwire Connectivity	USB	Ethernet, Serial RS-232, USB, USB Host
Wireless Connectivity	Bluetooth (Optional)	Bluetooth (Optional), Wi-Fi (Optional)
Enterprise Management	TSC Console	TSC Console
Programming Language	TSPL-EZD	TSPL-EZD
Machine Dimension	204 mm (W) x 164 mm (H) x 280 mm (D)	204 mm (W) x 164 mm (H) x 280 mm (D)
